About 3/4" Temperature and Pressure Relief 150 PSIG
This Apollo automatic temperature and pressure relief valve features a unique non-metallic coating which protects the element against galvanic and electromechanical corrosion by isolating it from the heated water. This coating is electrostatically applied for uniform coverage, then thermobonded, resulting in optimum adhesion for extended service life. CSA design certified at all settings to ANSI Z21.22. ASME Section IV rated at 125 psig and 150 psig settings for 3/4" NPT only.
- 3/4" male NPT inlet and 3/4" female NPT outlet
- Element length: 3"
- Weight: 64.4 lbs
- CSA capacity rating: 105,500 BTU/Hr.
- Meets HUD/FHA requirements
- Cast bronze body, stainless steel spring
- Rated 210 degrees F maximum
- CRN #0G0053.6C registered in all Canadian provinces and territories
- ASME capacity certified for 3/4" NPT only
3/4" Temperature and Pressure Relief 150 PSIG Product Specifications
| Model Number | TP334 |
|---|---|
| Product type | Temperature and Pressure |
| Size | 3/4x4 IN |
| End connection | Male x Female |
| Material | Bronze |
| Pressure | 150 PSI |
| Temperature | 210 DEG F |
| Seal material | Silicone |
| Part number | 18C-402-30 |
| End to end distance | 6-2/5 IN |
| Application | Water Heater |
| California residents | Warning: Prop65 Information applies. California Proposition 65 Warning |
| Collection | 18C-400 |
